Series 2100 Product Specifications
- Panels: 4¼" wide by ¼" thick; available in Vinyl-Lam and hardwood veneer faces, front and back
- Panel Connectors: Flexible vinyl, color-coordinated to panel selection
- Track: 2" x 1-1/8" aluminum, dark bronze, or clear finish
- Sound Seal: Flexible vinyl sweep strips mounted top and bottom, with wood molding mounted on both sides of the track, forming a 4-7/8" wide sweep surface
- Wheels: Nylon wheels on steel axle with ball bearings supplied as standard
- Lead Post: ¾" x 2¾" aluminum, color-coordinated to panel connectors
- Jamb Molding: 1-5/8" wide by 1" deep aluminum
- Latch: Dead latch with thumb turn on two sides; key locks or magnetic catch options available
- Handle: Molded PVC with finger access
- Width: Custom crafted to any width
- Height: Vinyl-Lam up to 12'1"; hardwoods up to 10'1"
- Stacking Space: 1¼" per foot, plus 2¾" for lead post
- WEIGHT: 8ft height is 12lbs per lin ft. 10ft height is 15lbs per lineal foot. 12ft height is 18 lbs per lineal foot.
* Field Sound Transmission Class: The Series 2100 door has a field sound transmission class rating of (FSTC) 21. Field tests were performed by Bruck, Richards & Chaudiere, Inc. of Seattle, Washington, following the procedures specified in ASTM designation E 336-77.
How to Order Church Room Dividers
-
Put the height and room width in the Measurement Box.
Please provide the highest and shortest height measurements (if there is any variation.)
Measuring Width and HeightList finished opening sizes. (A) Width: Finished wall-to-wall (or jamb) in feet and inches, e.g. 10'–5" x 7'–10";
(B) Height: From surface where track attaches to finished floor or top of carpet.
NOTE: For those areas where the floors are uneven take multiple height measurements, provide variances with quote or
order. For sound doors use tallest height measurement.
Dividers are sold by the lineal foot. So if room is 20ft wide you have 20 lin feet. Put “20” in the correct pricing box and it gives you the price at bottom of page - Enter the WIDTH IN WHOLE FEET (Rounded up) in the appropriate pricing box.
- OPTIONS
- Dividers can be made as a single door or as a pair (i.e. 2ea 10ft sections to make up a 20ft opening.
- If you are doing a pocket then select the Sliding Jamb Panel option
- The Intermediate Rolling Post is recommended for dividers over 30ft as it provides an intermediate post which hangs from the track and helps distribute the weight.
- The pull rod makes opening or closing a long divider easier.
4 Lock Options - We think the Thumb latch is better for churches than the keylock as you don’t have to worry about a lost key
5 Select Color
6 Click the Add to Cart Button
Put a note in with the dimensions to “Please provide pocket dimensions” and we will have the factory calculate the depth of your pocket and will email you with the answer.
How to Determine the Best Church Room Divider
We carry 4 types of dividers
The WF240 is the basic church room divider…there is a gap at the top where it hangs from track of about 3/8” + a ½” gap at bottom to allow for uneven floors. Due to the gap there is minimal sound reduction with the series 240. (imagine your opening covered with a 5/16" sheet of plywood but with gaps at the top and bottom)
WF 2100 is the entry level sound reduction divider (not sound proof) ...you can still hear talking but the noise level is reduced. Vinyl seals at top and bottom help reduce sound and airflow. (imagine your opening covered with a 5/16" sheet of plywood with vinyl seals to cover the gaps at the top and bottom)
WF 3300 is a double walled unit so it provides more sound reduction than the 2100 series but is still not sound proof. Vinyl seals at top and bottom help reduce sound and airflow.(imagine your opening covered with 2 sheets of 5/16" sheet of plywood with a half-inch air gap between the sheets and vinyl seals to cover the gaps at the top and bottom)
WF4100 is a double walled unit with extra sound dampening material in between the panels. Vinyl seals at top and bottom help reduce sound and airflow.(imagine your opening covered with 2 sheets of 5/16" sheet of plywood with a half-inch air gap plus heavy, sound dampening material between the sheets and vinyl seals to cover the gaps at the top and bottom). The WF4100 is close in sound reduction to a regular drywall interior wall.
All track and mounting hardware is included with the dividers.
Room dividers feature Free Shipping to the church.
Room Divider Installation
We do not provide installation or recommend installers but installation of room dividers is not difficult. Provided you have adequate ceiling structure (the track must screw into ceiling joists) most dividers can be installed using competent volunteer labor on a Saturday.
