Sound Rated 41 Acoustical Room Divider for Church up to 6ft 10 (priced per foot)

Series 4100 Product Specifications

• Series 4100 Product Specifications

• Panels: 6” (4166) or 8" (4188) wide by 1⁄2" thick medium density fiberboard with routed edge for vinyl hinging.
• Hinge assembly: 16 gauge steel, pantograph action for dualwall door assembly.
• Panel Connectors: Flexible vinyl, color-coordinated to panel selection, inserted and attached into routed edges. 4 color coordinated colors
• Track: 2” x 1-1/4” aluminum, pre-punched for screw fasteners for surface mounting.
• Sound Seal: Dual-wall door with internal acoustic material, flexible vinyl sweep strips mounted on top and bottom of the door. Wood molding mounted on both sides of track forming a wide sweep surface.
• Acoustical liner: Applied to inside faces of both walls.
• Wheels: Nylon-tired steel ball bearing wheels; 4 wheeled carriers on each volute and at lead post.
• Lead Post: Extruded aluminum, with jamb molding. Color-coordinated to panel connectors.
• Jamb Molding: 2-1/8” wide by 15/16” deep aluminum.
• Handle: Metal, Bronze or brushed satin chrome
• Latch: Deadlatch with thumbturn two-sides/one side and a range of keylock options available. Bronze or satin chrome finishes
• Width: Max size of a single partition - 150 sq ft. (i.e. if you have a 10ft H x 45ft W opening there will be 3 sections of 15ft w (x10ft H = 150 sf) each section pulls out independently and then the sections are clicked together when the divider is opened). If made as a pair (right/left) you would have a right side of 22.5ft and a left side of 22.5ft, each side would be comprised of two sections of 11.25fteach. The sections would have a double end lead post on one section which enables the two sections to click together.
• Height: up to 10'1"
• Stack Dimensions Width: 4166 Series 14 1/2".  4188 Series 18 1/2"
• Depth 4166 Series 2-1/4" per foot plus 9" for lead and anchor.
• Depth 4188 Series 2-1/4" per foot plus 9" for lead and anchor.

*Field Sound Transmission Class: The dual-walled Series 4100 Acoustic Partition has a field sound transmission class rating (FSTC) of 41 (STC 46). Field tests were performed by Bruck, Richards & Chaudiere, Inc. of Seattle, Washington following the procedures specified in ASTM designation E 336-90.

How to Order Church Room Dividers

Dividers are sold by the lineal foot. So if room is 20ft wide you have 20 lin feet. Put “20” in the correct pricing box and it gives you the price after you add to cart.

Dividers can be made as a single door or as a pair (i.e. 2ea 10ft sections to make up a 20ft opening. )

We think the Thumb latch is better for churches than the keylock as you don’t have to worry about a lost key

We carry 4 types of dividers

The WF240 is the basic church room divider…there is a gap at the top where it hangs from track of about 3/8” + a ½” gap at bottom to allow for uneven floors. Due to the gap there is minimal sound reduction with the series 240. (imagine your opening covered with a 5/16" sheet of plywood but with gaps at the top and bottom)

WF 2100 is the entry level sound reduction divider (not sound proof) ...you can still hear talking but the noise level is reduced. Vinyl seals at top and bottom help reduce sound and airflow. (imagine your opening covered with a 5/16" sheet of plywood with vinyl seals to cover the gaps at the top and bottom)

WF 3300 is a double walled unit so it provides more sound reduction than the 2100 series but is still not sound proof. Vinyl seals at top and bottom help reduce sound and airflow.(imagine your opening covered with 2 sheets of 5/16" sheet of plywood with a half-inch air gap between the sheets and vinyl seals to cover the gaps at the top and bottom)

WF4100 is a double walled unit with extra sound dampening material in between the panels. Vinyl seals at top and bottom help reduce sound and airflow.(imagine your opening covered with 2 sheets of 5/16" sheet of plywood with a half-inch air gap plus heavy, sound dampening material between the sheets and vinyl seals to cover the gaps at the top and bottom). The WF4100 is close in sound reduction to a regular drywall interior wall.

All track and mounting hardware is included with the dividers.

Room dividers feature Free Shipping to the church.

We do not provide installation or recommend installers but installation of room dividers is not difficult. Provided you have adequate ceiling structure (the track must screw into ceiling joists) most dividers can be installed using competent volunteer labor on a Saturday.
